Integrated Servo Motors & Drives
Leadshine iSV series integrated brushless servo motors are highly integrated servo systems at very competitive costs.
iSV series - integrated servo motor, 1000 ppr encoder, and drive. Motors are available in NEMA 23 frame size and can output up to 180W continuous power at peak speed of 4,000 RPM. A standard 1,000-line encoder is mounted, with the option of 500-line or 2500-line. The integrated high performance servo drive are DSP based adopting Leadshine's advanced control algorithm which can drive the motor at very high precision smoothly with very little noise and motor heating.
Key Features
Outputs of fault and in position signals can be directly sent to the motion controller or external control/monitoring devices
Step and direction control for standard models makes iSV series integrated servo motors easy to adopt for many OEM applications
Optional models with RS485 and CANopen controls available for advanced applications
NEMA 23 frame size with up to 180W continuous power output
Peak speed of 4,000 RPM with encoder options of 500, 1000, or 2500 lines
DSP-based drive with advanced control algorithm for high precision and smooth operation
